Lincoln Corsair: Glass, Frames and Mechanisms / Removal and Installation - Rear Door Window Control Switch

Lincoln Corsair 2020-2026 Service Manual / Body and Paint / Body and Paint / Glass, Frames and Mechanisms / Removal and Installation - Rear Door Window Control Switch

Special Tool(s) / General Equipment

Interior Trim Remover

Removal

NOTE: LH (left-hand) side shown, RH (right-hand) side similar.

Remove the rear door window control switch bezel assembly.
1. Release the locking tabs from the rear door window control switch bezel assembly.
  Use the General Equipment: Interior Trim Remover
1. Disconnect the rear door window control switch electrical connector and remove the rear door window control switch bezel assembly.

NOTE: This step is only necessary when installing a new component.

Remove the rear door window control switch from the bezel assembly.
1. Release the locking tabs from the rear door window control switch.
1. Remove the rear door window control switch from the bezel assembly.

Installation

To install, reverse the removal procedure.
