Lincoln Corsair: Rear View Mirrors / General Procedures - Power Mirrors Synchronization

Lincoln Corsair 2020-2024 Service Manual / Body and Paint / Body and Paint / Rear View Mirrors / General Procedures - Power Mirrors Synchronization

Synchronization

NOTE: The power folding mirrors may need to be synchronized any time the mirrors are folded or unfolded without using the exterior mirror control switch, or if a new power folding mirror is installed.

NOTE: The power telescoping mirrors may need to be synchronized any time the mirrors are extended or retracted without using the exterior mirror control switch, or if a new power telescoping mirror is installed.

NOTE: If the power folding or power telescoping mirrors are continuously electronically moved, the power lockout feature disables the system for approximately 3-10 minutes to prevent damage to the power fold motors. After 3-10 minutes have elapsed, normal operation resumes.

NOTE: F-150 power folding mirror procedure is shown in the video, other vehicles and power telescoping mirror procedure are similar.

  1. Fold or retract both mirrors by hand.
  1. Using the power folding/power telescoping mirror switch, operate the mirrors until an audible click is heard.
  1. Operate the power folding or power telescoping mirrors an additional 3 to 4 times to synchronize the mirrors.

   Click here to view a video version of this procedure.
