Lincoln Corsair: Front Seats / Removal and Installation - Front Seat Control Switch
Removal
NOTE:
Driver side shown, passenger side similar.
-
Remove the front door trim panel.
Refer to: Front Door Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
-
Remove the screws and the front seat control switch.
Installation
-
To install, reverse the removal procedure.
