Lincoln Corsair: Engine Cooling - 2.0L EcoBoost (177kW/240PS) – MI4 / Description and Operation - Engine Cooling - Component Location

Lincoln Corsair 2020-2025 Service Manual / Powertrain / Engine / Engine Cooling - 2.0L EcoBoost (177kW/240PS) – MI4 / Description and Operation - Engine Cooling - Component Location

NOTE: Coolant temperature will vary with ambient temperature and load. Temperatures shown are for ambient temperature of 38° C (100° F). Red arrows indicate a temperature over 90° C (194° F), Orange arrows indicate a temperature of approximately 90° C (194° F), Blue arrows indicate a temperature below 90° C (194° F).

Front Wheel Drive (FWD)


Item Description
1 Radiator
2 Upper radiator hose
3 Cylinder block
4 Coolant bypass hose
5 Coolant inlet connector
6 Degas bottle hose assembly
7 Radiator overflow hose
8 Lower radiator hose
9 Coolant pump
10 Thermostat
11 Coolant pump adapter
12 Cylinder head gasket
13 Cylinder head
14 Degas bottle
15 Turbocharger coolant inlet hose
16 Coolant outlet tube
17 Degas bottle-to-engine hose
18 Turbocharger coolant outlet hose
19 Turbocharger
20 EGR cooler
21 EGR hose assembly
22 Heater core
23 Heater core hose assembly
24 Coolant outlet connector
25 Transmission fluid heater coolant control valve inlet hose
26 Transmission fluid heater coolant control valve
27 Transmission fluid heater coolant control valve outlet hose
28 Transmission oil cooler
29 Cabin heater coolant pump hose assembly
30 Cabin heater coolant pump

All Wheel Drive (AWD)


Item Description
1 Radiator
2 Upper radiator hose
3 Cylinder block
4 Coolant bypass hose
5 Coolant inlet connector
6 Degas bottle hose assembly
7 Radiator overflow hose
8 Lower radiator hose
9 Coolant pump
10 Thermostat
11 Coolant pump adapter
12 Cylinder head gasket
13 Cylinder head
14 Degas bottle
15 Turbocharger coolant inlet hose
16 Coolant outlet tube
17 Degas bottle-to-engine hose
18 Turbocharger coolant outlet hose
19 Turbocharger
20 EGR cooler
21 EGR hose assembly
22 Heater core
23 Heater core hose assembly
24 Coolant outlet connector
25 Power transfer unit
26 Transmission fluid heater coolant control valve inlet hose
27 Transmission fluid heater coolant control valve
28 Transmission fluid heater coolant control valve outlet hose
29 Transmission oil cooler
30 Heater hose assembly
31 Cabin heater coolant pump hose assembly
32 Cabin heater coolant pump
