Lincoln Corsair: Rear Seats / Removal and Installation - Heated Rear Seat Module
Removal
NOTE:
The heated rear seat module is located under the LH (left hand) rear seat cushion substrate.
-
Remove the heated rear seat module.
-
Remove the pin-type retainer.
-
Remove the heated rear seat module from the rear seat cushion substrate.
-
Disconnect the electrical connectors.
Installation
-
To install, reverse the removal procedure.
