Lincoln Corsair: Wipers and Washers / Removal and Installation - Rear Window Wiper Motor
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
Remove the rear window wiper pivot arm.
Refer to: Rear Window Wiper Pivot Arm (501-16)
.
-
Remove the liftgate trim panel.
Refer to: Liftgate Trim Panel (501-05)
.
-
-
Disconnect the rear wiper motor electrical connector and position the harness aside.
-
Remove the rear wiper motor retainers and the rear wiper motor.
Torque:
97 lb.in (11 Nm)
Installation
-
To install, reverse the removal procedure.
