Lincoln Corsair: Supplemental Restraint System / Description and Operation - Airbag and Seatbelt Pretensioner Supplemental Restraint System (SRS) - Component Location
Lincoln Corsair 2020-2023 Service Manual / Body and Paint / Body and Paint / Supplemental Restraint System / Description and Operation - Airbag and Seatbelt Pretensioner Supplemental Restraint System (SRS) - Component Location
.jpg)
| Item | Description |
|---|---|
| 1 | Driver and passenger side curtain airbag |
| 2 | Driver second row seat side airbag |
| 3 | Driver side airbag |
| 4 | Driver airbag |
| 5 | Clockspring |
| 6 | Driver and passenger knee airbag |
| 7 | Passenger airbag (includes canister vent) |
| 8 | Passenger side airbag |
| 9 | Passenger second row seat side airbag |
.jpg)
| Item | Description |
|---|---|
| 1 | Passenger C-pillar side impact sensor |
| 2 | Overhead console (includes PAD indicator) |
| 3 | BECMB |
| 4 | Driver C-pillar side impact sensor |
| 5 | Driver front door side impact sensor |
| 6 | Driver seat position sensor |
| 7 | RCM |
| 8 | Driver and passenger front impact severity sensors |
| 9 | Passenger seat position sensor |
| 10 | Passenger front door side impact sensor |
| 11 | OCSM (includes OCS sensor and gel-filled bladder) |
.jpg)
| Item | Description |
|---|---|
| 1 | Driver seatbelt retractor (includes retractor pretensioner and anchor pretensioner) |
| 2 | Driver seatbelt buckle (includes buckle sensor) |
| 3 | Front passenger seatbelt buckle (includes buckle sensor and Belt Tension Sensor (BTS)) |
| 4 | Front passenger seatbelt retractor (includes retractor pretensioner, retractor load limiter and anchor pretensioner) |
| 5 | Rear passenger side outer seatbelt retractor (includes retractor pretensioner) |
| 6 | Rear passenger side outer seatbelt buckle (includes seatbelt buckle switch) |
| 7 | Rear center seatbelt buckle (includes seatbelt buckle switch) |
| 8 | Rear driver side outer seatbelt buckle (includes seatbelt buckle switch) |
| 9 | Rear driver side outer seatbelt retractor (includes retractor pretensioner) |
Description and Operation - Airbag and Seatbelt Pretensioner Supplemental Restraint System (SRS) - Overview
Overview
The RCM continually receives and monitors inputs from the OCSM and various other hard-wired switches and sensors. If the RCM
detects a sudden vehicle deceleration and/or lateral deceleration
based on the information received from the various sensors and
determines that deployment is necessary, it applies voltage and current
to deploy the appropriate SRS components...
